VMDR10 In-line pressure relief valves

VMDR10 valves have the task of limiting the pressure of a hydraulic circuit to the set calibration value, avoiding damage to the circuit itself and to the mechanical structure connected to it. 3 Inside each hydraulic circuit, the maximum pressure valves are fundamental components to prevent damage from overpressure due to impacts or excessive loads. The valves of the VMDR10 series are direct operated pressure relief valves for operating flow rates up to 20 lpm and maximum pressures of 350 bar (5075 PSI). The parts-in-body execution allows its installation in line inside the hydraulic system. The body and all external components are made of high-strength steel and subjected to galvanizing to resist the action of corrosive agents. The internal components are also made of steel, hardened and ground where necessary to ensure the correct performance level of the valve.
